規格 Spec
型號 Model

楔心行程
Plunger stroke
mm

爪行程直徑
Jaw stroke Dia.
mm

最大夾持直徑
Max chucking Dia.
mm

最小夾持直徑
Min chucking Dia.
mm

容許油壓缸推力

Max.D.B.Pull

kgf

BF-206 A5

12

5.5

169

15

2700

BF-208 A5

16

7.4

210

13

4430

BF-208 A6

16

7.4

210

13

4430

BF-210 A6

19

8.8

254

31

5440

BF-210 A8

19

8.8

254

31

5440

BF-212 A8

23

10.6

304

34

7000

BF-215 A11

23

10.6

381

50

9000

BF-218 A11

23

10.6

450

50

7240

BF-224 A20

26

12

610

150

9177

規格 Spec
型號 Model

最大夾持力
Max clamping force
kgf

最高轉速
Max RPM

慣性矩
I
kg*m2

重量
Weight
kg

帶法蘭重量
Weight(Ad.)
kg

適合油壓缸
Matched cylinders

BF-206 A5

7000

6000

0.06

11.5

13.3

H-1246/HK-1246

BF-208 A5

10900

5000

0.19

23.5

25.4

H-1552/HK-1552

BF-208 A6

10900

5000

0.19

23.5

24.3

H-1552/HK-1552

BF-210 A6

14100

4200

0.34

36.3

41

H-1875/HK-1875

BF-210 A8

14100

4200

0.34

36.3

39.3

H-1875/HK-1875

BF-212 A8

18300

3300

0.79

62

65.7

H-2091/HK-2091

BF-215 A11

22900

2500

2.42

123.7

130.7

H-2511/HK-2511

BF-218 A11

18355

1500

3.798

140

151

H-2511/HK-2511

BF-224 A20

23861

1000

15.2

284

299

ML3320

規格 Spec
型號 Model

A

B

B (Ad.)

C(H6)

D

D1

D2

E

E1

F

Gmax

Gmax(Ad.)

Gmin

Gmin(Ad.)

H

J

BF-206 A5

169

81

91

140

104.8

82.56

116

5

15

45

11

26

-1

14

19

20

BF-208 A5

210

91

109

170

133.4

82.56

104.8

5

23

52

14.5

37.5

-1.5

21.5

20.5

30

BF-208 A6

210

91

103

170

133.4

106.38

150

5

17

52

14.5

31.5

-1.5

15.5

20.5

30

BF-210 A6

254

100

120

220

171.5

106.38

133.4

5

25

75

8.5

33.5

-10.5

14.5

25

45

BF-210 A8

254

100

113

220

171.5

139.72

190

5

18

75

8.5

26.5

-10.5

7.5

25

45

BF-212 A8

304

110

122

220

171.5

139.72

190

6

18

91

8

26

-15

3

28

50

BF-215 A11

381

133

149

300

235

196.87

260

6

22

117.5

11

33

-12

10

39

60

BF-218 A11

450

133

149

300

235

196.87

260

6

22

117.5

7

29

-16

6

43

-

BF-224 A20

610

134

155

520

463.6

412.78

463.6

6

25

205

16

41

-10

15

38

-

規格 Spec
型號 Model

K max

L

L1

L1(Ad.)

M

N

P

Q max

Q min

R max

R min

S

T

U

BF-206 A5

M55×2

4-M10

16

16

37

73

20

32

29.3

22.8

9.3

31

12

3-M6

BF-208 A5

M60×2

4-M12

20

17

38

95

25

38.7

35

29.8

14.8

35

14

6-M10

BF-208 A6

M60×2

4-M12

20

18

38

95

25

38.7

35

29.8

14.8

35

14

3-M6

BF-210 A6

M85×2

4-M16

22

18

43

110

30

51

46.6

33.8

14.3

40

16

6-M12

BF-210 A8

M85×2

4-M16

22

24

43

110

30

51

46.6

33.8

14.3

40

16

3-M8

BF-212 A8

M100×2

4-M18

23

25

51

130

30

61.3

56

45.8

15.8

50

21

3-M9

BF-215 A11

M130×2

4-M20

30

28

66

165

43

82

76.7

46.8

13.8

62

22

4-M10

BF-218 A11

M130×2

4-M20

30

28

66

165

43

82

76.7

79.75

15.25

62

22

3-M10

BF-224 A20

M215×3

8-M24

35

35

73

180

60

139.9

133.9

87.5

24.5

65

25

3-M10
